Rice Hull Carbonizer, Rice Husk Charcoal Making Machine

Rice Hull Carbonizer

Rice hull carbonizer has been hot equipment to produce carbonized rice husk. With the petroleum-insufficiency trend, countries need to find eco-friendly alternative resources. Rice hull charcoal is a great substitute. TM-Machine provides seven models, including the batch type and continuous type. These machines are durable and environment-friendly. Besides, this machine has been applied to carbonize wood, coconut shell, or other materials. Tell us what you need now.

sales@tm-recycle.com

Benefits

Alternative of Traditional Energy
The Middle East and Africa are used to be large producers of oil. With the decreasing oil and increasing energy consumption, more and more people have to find new energy to replace oil. Carbonized rice hull is a great material to provide heat for industry or other equipment. It has a low cost and good effectiveness.

As Carbonized Rice Hull Fertilizer
Carbonized rice husk is light and has super absorbent. Its PH values show alkaline. It will help plants to absorb nutrients well. In addition, some elements, like K, P, Ca, Mg, make plants grow better. Some investors will use the final rice charcoal as the raw materials of fertilizer. It has a low cost and good effectiveness.

Make Activated Husk Charcoal
This charcoal has a porous structure and good gas permeability. Accordingly, it is usually activated charcoal to reduce the odor. Some customers will use other equipment to reprocess carbonized rice husk. In addition, a part of customers will use rice hull charcoal to make charcoal rod or ball for BBQ or Shisha.

Working Process

Put rice husk into feeder. Then the feeder feeds it into the sealed reactor. After high-temperature caronizing process, the rice hull charcoal will be discharged. Besides, there is waste combustible gas in the reactor. After recycled by combustible gas recycling system, customers can reuse gas as fuel.
TM-Machine rice hull carbonizer grasps the newest carbonizing technology. When you choose equipment to recycle rice hull, it is the best choice. We insist on the goal of turning waste into resources with high efficiency and high value for customers. Choose a suitable one from seven models. We are also would like to get your message.

Advantages

Well-functioning Rice Husk Carbonization Furnace
Firstly, in this machine, the material of every part is tested and has good performance. For example, the reactor has high-temperature resistance. Secondly, in order to enhance the security of the rice husk carbonization plant, some devices are needed, like a pressure gauge, thermometer, explosion-proof hole.

Inexpensive Rice Hull Carbonizer Price
We believe you have already searched for several suppliers online. TM-Machine is a top-rated manufacturer. Our rice husk charcoal making machine cost is fair. We not only offer high-quality and high-efficiency machines but also provide customer-oriented service. Accordingly, the price can’t be the lowest. It is definitely worthy of your investment.

A Range of Comprehensive After-sales Service
Good after-sales service is conducive to reduce costs for customers in the future. TM-Machine is willing to provide you with some services, like project plans from professional engineers, installation, maintenance, upgrading, one-year guarantee, technical support. If you have other requirements, just call us. Many suppliers don’t have a good post-sales service, which will lead to many costs and problems in the future. Besides these mentioned services, we also have others.

20+ Cases & 10-year Experience
We have established good relationship with many customers from more than twenty countries, such as Turkey, Spain, Ukraine, Ghana and so on. Some customers visited TM-Machine to check the running condition and paid a deposit. Then we gave them satisfactory plans according to their condition. In addition, some customers required some special need, like capacity, discharging method. Finally, we always offer suitable plans for them.

Recycled Combustible Gas – Another Energy Alternative

In the carbonized rice hull production, there is a large of waste gas generated. In order to effectively recycle the gas, every biochar pyrolysis machine is equipped with a cyclone dust collector and condensers to recycle the waste combustible gas. The recycled combustible gas has two uses. Firstly, it can enter into a combustion chamber to replace fuel. Secondly, it can be stored for other industries’ uses.

Technical Parameters

Model	TMT-J12	TMT-J18	TMT-J40	TMT-05 Pro (skid-mounted)	TMT-10	TMT-30	TMT-50
Input Capacity	12m³/batch	18m³/batch	40m³/batch	0.3-0.5m³/h	2-4m³/h	7-9m³/h	10-15m³/h
Reactor Size	φ1900mm * L4500mm	φ1900mm * L6600mm	φ2800mm * L7100mm	φ830mm * L5500mm	φ1300mm * L14051mm	φ1700mm * L14180mm	φ2000mm * L14260mm
Land for Equipment (LWH, Standard Configuration)	9m6m6m	12m6m7m	15m18m7m	10m8m3.9m	29m15m5m	30m15m8m	35m18m9m
Weight (Standard Configuration)	18T	22T	34T	15T	35T	35T	49T
Energy Consumption (Standard Configuration)	11kw/h	13.5kw/h	25kw/h	31kw/h	34.7kw/h	61.5kw/h	116kw/h
Working Method	Batch			Fully continuous
Feeding Requirement	/			Size: ≤20mm; moisture: ≤15%; strong liquidity
Structure	Horizontal rotation			Double barrel single hearth	Double barrel double hearth
Speed	0-2RPM			1-9RPM
Control Method	Control by buttons			Automatic control
Reactor Material	Q245R				Q245+310S
Pressure	Micro negative pressure
Heating Material	Diesel, natural gas, heavy oil, biomass, etc.
Heating Method	Direct heating
Noise (dB)	≤80
Condenser	Circulating water cooling
Rotation Method	External gear rotation
